Blackmer Mouvex positive displacement pump - Stock Ref 3693
BLACKMER "Mouvex" model C4ICVT eccentric disc type positive displacement pump constructed in 316 grade stainless steel, supplied new in 1999. 50mm dia inlet/outlet connections. Pump feature include: self priming, high volumetric efficiency, flush and clean in place, gentle product handling, low linear speed, double bellows, stainless steel shaft seals, high suction and discharge pressure. Maximum parameters for the pump are 750rpm, 4m³/hr, 10 bar discharge pressure. The pump is driven by a 0.37 kw 1330rpm motor via a handwheel operated variable speed gearbox 18-92rpm range. Fitted motor stop/start and mounted onto a stainless steel mobile cart.
